| Shape features | 7 Inch Capacitive Screen, Aluminum Print Head, The USB Interface |
| Dimension | 245x130x45mm |
| Net weight | 0.45kg |
| Nozzle | TIJ Hot Foaming Nozzle |
| Character type | high-definition printing character, dot matrix font, Simplified, Traditional Chinese and English |
| Printing line | 1-8 lines (adjustable) |
| Printing height | 1.2mm-12.7mm and 1.2mm-25.4mm |
| Print code | bar code, QR Code |
| Printing distance | 1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm) |
| Automatic print | date, time, batch number shift and serial number, etc |
| Printing speed | 60m/min |
| Ink type | Quick-dry solvent environmental ink, water-based ink and oily ink |
| Ink color | black, white, red, blue, yellow, green, invisible |
| Ink volume | 42ml(usually can print 800,000 characters) |
| External interface | Power and optoelectronic interface, DVI Cable Interface, USB Interface |
| Adapter Parameters | 100-240V AC Input |
| Print Library | Synchronous Machine Library |
| Spray Printing Precision | 300 DPI |
| Information is Stored | Unlimited Storage |
| Printing material | board, carton, stone, pipe, cable, metal, plastic product, electronic, the fiber board, light steel keel, aluminum foil, etc. |
